Reactor 290 Alloy

Reactor Alloy 29 Eagle90 REA01As(M)

  • S
  • M
  • L
  • XL
  • XXL
What is my size?
€3,999.00
Checkout is not available in your country. Contact your local dealer to order

Aggressive trail geometry

Adjustable geometry with Flip Chip

Advanced 4-bar Horst linkage for exceptional suspension dynamics

About Reactor 290 Alloy

From concept through to design, the Kinematics, the geometry and specification; the Reactor is designed from the ground up to be the ultimate aggressive trail bike. It is at home on technical climbs, but happiest when thrashing the most technical trails you can point it at.

The Reactor frame is crafted from hydroformed triple butted 6061 aluminum. To reduce unsprung mass the seatstays on the Reactor are molded from carbon fibre. All frames are available for 27.5” or 29” wheel sizes. All frames feature a flip chip to adjust the geometry from a trail to a rail setting.

The Reactor is designed to reward the rider and ensure you get that stoke factor in on any ride.

Aggressive trail geometry

From the initial concept to final design, the Reactor was developed as the ultimate aggressive trail bike. Whether tackling steep, technical climbs or charging down rough descents, the geometry and kinematics are tuned to deliver a bike that excels in both uphill efficiency and downhill control. Its trail-shredding DNA is baked into every detail, rewarding riders who want a playful yet capable all-rounder.

Aggressive trail geometry

Adjustable geometry with Flip Chip

The Reactor features a flip chip in the suspension linkage, offering two distinct geometry modes: “Trail” and “Rail.” The Trail mode is balanced for all-around riding with efficient climbing and stable descending, while the Rail mode lowers the bottom bracket and slackens the head angle for more aggressive downhill performance. This adjustability makes the Reactor incredibly versatile, adapting to a wide range of trails and rider preferences.
Adjustable geometry with Flip Chip

Advanced 4-bar Horst linkage for exceptional suspension dynamics

Using a 4-bar Horst linkage, the Reactor is tuned for exceptional suspension dynamics. It boasts high anti-squat in climbing gears for pedaling efficiency and reduced anti-squat at higher speeds to stay active and plush. A progressive suspension rate ensures small bump sensitivity, mid-stroke support for cornering and pumping, and a controlled end stroke for bigger hits. Balanced anti-rise allows the bike to remain composed under braking, maintaining grip and rider stability.

Advanced 4-bar Horst linkage for exceptional suspension dynamics

Specifications

  • Material
    Aluminium
  • Fork
    Rockshox Lyric Select+, Charger 3.1 RC2, Boost 15x110, Debonair+, 160mm travel
  • Rear Shock
    Rockshox Super Deluxe Select+, 210x55
  • Groupset
    Sram Eagle 90
  • Rear Derailleur
    Sram Eagle 90
  • Crank
    Sram Eagle 90, 12-speed, 165mm, 30T, B148, DUB
  • Cassette
    Sram XS-1270 T-Type 10-52
  • Brake Type
    Post Mount
  • Front Brake
    Sram Maven, 4 piston, mineral oil, steel backed organic pads
  • Rear Brake
    Sram Maven, 4 piston, mineral oil, steel backed organic pads
  • Wheelset
    DT Swiss M1900 Spline, 29", 370LN hubs, 30mm inner width
  • Outer Tyre
    Schwalbe Magic Mary/Nobby Nic Super Trail, TLE, 29x2,4"
  • Handlebar
    Nukeproof Horizon V2, 31.8mm, 25mm Rise
  • Stem
    Nukeproof Horizon, 45mm, Black
  • Saddle
    Nukeproof Horizon SL
  • Range
    Trail/All-Mountain
